140DAO85300 | AC OUT 24-240V 4X8 – Schneider Electric

Name: 140DAO85300 - Discrete output module Modicon Quantum - 32 O - 20..253 V AC | Schneider Electric
Brand: Schneider Electric
SKU: 140DAO85300
Price: 295699.82 INR
Availability: BackOrder

SKU: 140DAO85300

Original price was: ₹343,837.00.Current price is: ₹295,699.82. Excl. GST

Dispatch By : 17 Weeks

20 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Specifications

Main
Range of product	Modicon Quantum automation platform
Product or component type	AC discrete output modules
Discrete output number	32
Complementary
Group of channels	4 groups of 8 channels
Supply frequency	47…63 Hz
maximum voltage drop	1.5 V
Discrete output voltage	20…253 V AC
Addressing requirement	2 output words
Absolute maximum output	300 Vrms for 10 s AC 400 Vrms 1 cycle AC
Maximum load current	16 A rms per module 4 A rms per group 0.88 mA 230 V off state leakage per output 1 A rms 20…253 V per output
Surge current	2.5 A during 1 ms
DV/dt	400 V/ms
Response time	<= 0.5 ms at state 0 to state 1 <= 0.5 ms at state 1 to state 0
Protection type	Internal output protection by 4 A fuse Internal by RC filter
Power dissipation	1.60 + (1.0 V x total module load current)
Marking	CE
Local signalling	1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status
Bus current requirement	320 mA
Module format	Standard
Net weight	0.45 kg
Environment
Product certifications	cUL FM Class 1 Division 2
Standards	CSA C22.2 No 142 UL 508
Electromagnetic compatibility	Electrostatic discharge immunity test – test level: 4 kV (contact discharge) conforming to IEC 801-2 Electrostatic discharge immunity test – test level: 8 kV (air discharge) conforming to IEC 801-2 Susceptibility to electromagnetic fields – test level: 10 V/m (80…1000 MHz) conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	4.700 cm
Package 1 Width	16.400 cm
Package 1 Length	31.500 cm
Package 1 Weight	492.000 g
Contractual warranty
Warranty (in months)	18
