140DDI35310 | DC IN 24V 4 X 8 SOURCE – Schneider Electric

Name: 140DDI35310 - Discrete input module Modicon Quantum - 32 I - 24 V DC | Schneider Electric
Brand: Schneider Electric
SKU: 140DDI35310
Price: 136909.42 INR
Availability: BackOrder

SKU: 140DDI35310

Original price was: ₹159,197.00.Current price is: ₹136,909.42. Excl. GST

Dispatch By : 17 Weeks

14 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Specifications

Main
Range of product	Modicon Quantum automation platform
Product or component type	Low voltage dc discrete input modules
Discrete input number	32
Complementary
Group of channels	4
Logic input	Negative (source)
Discrete input voltage	24 V DC
Input voltage limits	19.2…30 V
Voltage state 1 guaranteed	-30…-15 V DC
Voltage state 0 guaranteed	-5…0 V DC
Current state 1 guaranteed	>= 2.5 mA at Us = – 14 V
Current state 0 guaranteed	<= 0.5 mA
Addressing requirement	2 input words
Input impedance	2400 Ohm
Maximum leakage current	200 mA at Us = 5.5 V and Uin = 4 V
Absolute maximum input	30 V continuous 50 V during 1 ms decaying pulse
Response time	<= 1 ms from state 0 to state 1 <= 1 ms from state 1 to state 0
Protection type	Input protection by resistor limited
Power dissipation	1.5 W + (0.26 x number of points on)
Isolation between group and bus	1780 Vrms for 1 minute
Isolation between group	500 Vrms for 1 minute
Local signalling	1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status
Marking	CE
Bus current requirement	330 mA
Module format	Standard
Net weight	0.3 kg
Environment
Standards	UL 508 CSA C22.2 No 142
Product certifications	RINA GOST FM Class 1 Division 2 C-Tick RMRS
Resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	16.3 cm
Package 1 Width	4.5 cm
Package 1 Length	31.2 cm
Package 1 Weight	412.0 g
Contractual warranty
Warranty (in months)	18
