140DDO84300 | DC OUT 10-60V 2 X 8 SOURCE – Schneider Electric

Name: 140DDO84300 - Discrete output module Modicon Quantum - 16 O - 10..60 V DC | Schneider Electric
Brand: Schneider Electric
SKU: 140DDO84300
Price: 143198.60 INR
Availability: BackOrder

SKU: 140DDO84300

Original price was: ₹166,510.00.Current price is: ₹143,198.60. Excl. GST

Dispatch By : 17 Weeks

12 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Specifications

Main
Range of product	Modicon Quantum automation platform
Product or component type	Dc discrete output module
Discrete output number	16
Complementary
Group of channels	2 groups of 8
Discrete output logic	Positive logic (source)
Addressing requirement	1 output word
Discrete output voltage	10…60 V DC
Output voltage limits	10.2…72 V
Absolute maximum output	72 V permanent
Maximum voltage drop	<1 V 2 A
Maximum load current	12 A per module 6 A per group
Surge current	7.5 A for 50 s
Response time	<= 1 ms at state 0 to state 1 <= 1 ms at state 1 to state 0
Maximum leakage current	1 mA 60 V
Load inductance	Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz)))
Associated fuse rating	2 A each point 8 A per group
Isolation between channels and bus	2500 Vrms DC for 1 minute
Isolation between group	700 Vrms DC for 1 minute
Protection type	Internal output protection by 8 A fuse per group
Power dissipation	1 W + (1 V x total module load current)
Marking	CE
Local signalling	1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status
Bus current requirement	160 mA
Module format	Standard
Net weight	0.45 kg
Environment
Product certifications	GOST RMRS FM Class 1 Division 2 C-Tick
Standards	CSA C22.2 No 142 UL 508
Resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	4.73 cm
Package 1 Width	16.33 cm
Package 1 Length	30.91 cm
Package 1 Weight	452.6 g
Contractual warranty
Warranty (in months)	18
