170ADO34000 | Momentum Base - 16DO 24VDC, 0.5A - Schneider Electric - Image 1
Click to enlarge

    170ADO34000 | Momentum Base – 16DO 24VDC, 0.5A – Schneider Electric

    SKU: 170ADO34000

    Original price was: ₹50,220.00.Current price is: ₹33,145.20. Excl. GST

    Dispatch By : 20 Weeks

    Dispatch By : 20 Weeks

    18 People watching this product now!

    Order protection

    Buy with complete confidence.

    We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

    Buyer protection on every order
    Global DeliveryShipped pan-India and to export markets.
    On-Time DeliveryPacked and dispatched on schedule.
    100% OriginalFrom brand-authorised channels only.
    GST InvoiceCompliant, ITC-ready tax invoice.
    Secure PaymentEncrypted, trusted payment gateways.
    Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

    Specifications

    Main
    Range of productModicon Momentum automation platform
    Product or component typeDiscrete output base DC
    Group of channels2 groups of 8 outputs
    Current per channel0.5 A
    Discrete output number16
    Complementary
    Output overload protectionOutputs electronically protected
    Terminals description PLC n°1(14)OUT_DIS#14
    (2L+)PW_POS
    (L+)PW_POS
    (5)OUT_DIS#5
    (1)OUT_DIS#1
    (15)OUT_DIS#15
    (M-)PW_NEG
    (12)OUT_DIS#12
    (8)OUT_DIS#8
    (4)OUT_DIS#4
    (16)OUT_DIS#16
    (6)OUT_DIS#6
    (2)OUT_DIS#2
    (10)OUT_DIS#10
    (11)OUT_DIS#11
    TB
    (13)OUT_DIS#13
    (7)OUT_DIS#7
    (9)OUT_DIS#9
    (3)OUT_DIS#3
    (1L+)PW_POS
    Local signalling16 LEDs for channel status
    Height141.5 mm
    Width125 mm
    Depth47.5 mm
    Net weight0.21 kg
    Environment
    Protective treatmentTC
    MarkingCE
    Packing Units
    Unit Type of Package 1PCE
    Number of Units in Package 11
    Package 1 Height5.7 cm
    Package 1 Width18.2 cm
    Package 1 Length26.0 cm
    Package 1 Weight384.0 g
    Unit Type of Package 2S03
    Number of Units in Package 210
    Package 2 Height30 cm
    Package 2 Width30 cm
    Package 2 Length40 cm
    Package 2 Weight3.84 kg
    Unit Type of Package 3P06
    Number of Units in Package 380
    Package 3 Height75.0 cm
    Package 3 Width40.0 cm
    Package 3 Length80.0 cm
    Package 3 Weight43.9 kg
    Contractual warranty
    Warranty (in months)18
