Schneider Electric NSX100B 25kA AC 4P3D 32A TMD (C10B6TM032)
Product Overview
The Schneider Electric NSX100B is a high-performance molded case circuit breaker designed for reliable protection of electrical installations. With a breaking capacity of 25kA, this 4-pole (3 protected poles + 1 neutral) device offers thermal-magnetic protection (TMD) with a rated current of 32A.
Key Features
- Model: NSX100B
- Reference: C10B6TM032
- Breaking Capacity: 25kA AC
- Number of Poles: 4P3D (4 poles with 3 protected poles + neutral)
- Rated Current: 32A
- Protection Type: Thermal-Magnetic (TMD)
- Brand: Schneider Electric
- Compact Design: Space-saving solution for electrical panels
- High Performance: Reliable protection against overloads and short-circuits
Applications
Ideal for commercial and industrial applications including:
- Electrical distribution panels
- Motor protection circuits
- HVAC systems
- Industrial machinery
- Commercial buildings
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Insulation Voltage (Ui) | 690V |
| Rated Operational Voltage (Ue) | 400V AC |
| Frequency | 50/60Hz |
| Mounting | Fixed |
| Terminal Type | Screw clamp |
| Standards | IEC 60947-2 |
Why Choose This Product?
- Manufactured by Schneider Electric – a global leader in electrical solutions
- High breaking capacity for enhanced safety
- Precise thermal-magnetic protection
- Durable construction for long service life
- Easy installation and maintenance
For more technical details or installation guidance, please contact our support team at myelectric.in
