Schneider Electric NSX100H 70kA AC 4P4D 100A MCCB (C10H42D100)

Key Features:

• Model: NSX100H (C10H42D100)
• Breaking Capacity: 70kA at 415V AC
• Number of Poles: 4P (4 Poles)
• Tripping Unit: Micrologic 2.2 (Thermal Magnetic)
• Rated Current: 100A (Fixed)
• Mounting: Fixed Type
• Standards: IEC 60947-2, CE Certified
• Termination: Front and Rear Accessible
• Applications: Industrial, Commercial, and Utility Power Distribution

Product Description:

The Schneider Electric NSX100H is a high-performance molded case circuit breaker (MCCB) designed for reliable protection in demanding electrical installations. With a breaking capacity of 70kA, it ensures safety in case of short circuits. The Micrologic 2.2 trip unit provides precise thermal-magnetic protection for overloads and short circuits.

This 4-pole version is ideal for three-phase systems with neutral protection. The compact design and robust construction make it suitable for panel builders and electrical contractors looking for dependable circuit protection.

Typical Applications:

• Main distribution boards
• Motor protection circuits
• Industrial control panels
• Commercial building electrical systems
• Data center power distribution

Compatibility:

This MCCB is compatible with Schneider Electric’s ComPact NSX range of accessories including shunt trips, auxiliary contacts, and communication modules.

Why Choose This Product?

• Schneider Electric quality and reliability
• High breaking capacity for enhanced safety
• Precise protection with Micrologic 2.2 trip unit
• Easy installation and maintenance
• Wide range of compatible accessories
