LC1G1504KUEN – TeSys Giga Contactor 4P 150A 100-250V AC/DC
Product Description
The LC1G1504KUEN from Schneider Electric’s TeSys Giga range is a high-performance 4-pole contactor designed for heavy-duty industrial applications. With a rated current of 150A and compatible with both AC and DC control circuits (100-250V), this contactor offers reliable switching for motor control and power distribution systems.
Key Features
- Rated Current: 150A
- Number of Poles: 4
- Control Voltage: 100-250V AC/DC
- Contact Material: Silver alloy for high durability
- Mechanical Life: Up to 10 million operations
- Electrical Life: Up to 1 million operations at rated current
- Mounting: DIN rail or screw mounting
- Standards: IEC 60947-4-1, UL 508, CSA C22.2
Applications
- Industrial motor control
- HVAC systems
- Power distribution
- Pump and compressor control
- Heavy machinery
Technical Specifications
| Parameter | Value |
|---|---|
| Product Range | TeSys Giga |
| Rated Operational Current (Ie) | 150A at 400V AC-3 |
| Rated Insulation Voltage (Ui) | 690V |
| Rated Operational Voltage (Ue) | 690V AC, 250V DC |
| Power Consumption | 30VA (AC), 30W (DC) |
| Weight | Approx. 1.8 kg |
| Dimensions (H x W x D) | 145 x 90 x 120 mm |
Why Choose Schneider Electric TeSys Giga?
Schneider Electric’s TeSys Giga contactors are known for their exceptional reliability and performance in demanding environments. The LC1G1504KUEN offers:
- Robust construction for industrial applications
- High electrical and mechanical endurance
- Wide voltage range compatibility
- Easy installation and maintenance
- Global certifications and approvals
Available now at myelectric.in – your trusted source for quality electrical components.
