PIC101N | Process Indicator, Universal Input, Sensor Supply – Selec
The PIC101N is a versatile process indicator designed for industrial applications. It supports universal input and provides sensor supply, making it suitable for a wide range of process monitoring tasks.
Key Features:
- Universal Input: Compatible with various input types including thermocouples, RTDs, voltage, current, and resistance.
- Sensor Supply: Built-in sensor supply for 2-wire and 3-wire transmitters.
- High Accuracy: Offers high precision measurement with minimal error.
- Dual Display: Features a dual-line display for simultaneous viewing of process values and setpoints.
- Programmable: Allows customization of input types, display parameters, and alarm settings.
- Alarm Function: Equipped with dual alarm outputs for process control and safety.
- Communication Options: Supports RS485 communication for data logging and remote monitoring.
- Compact Design: Compact and robust design suitable for panel mounting.
- Wide Power Supply Range: Operates on a wide range of power supply voltages (85-265V AC/DC).
- Environmental Protection: Designed to withstand harsh industrial environments with IP65 front panel protection.
Applications:
The PIC101N is ideal for use in various industries including:
- Process control and monitoring
- Temperature and pressure measurement
- Flow and level monitoring
- HVAC systems
- Energy management systems
Technical Specifications:
| Parameter | Specification |
|---|---|
| Input Types | Thermocouples, RTDs, Voltage, Current, Resistance |
| Sensor Supply | 24V DC |
| Accuracy | ±0.1% of full scale |
| Display | Dual-line, 4-digit LED |
| Alarm Outputs | 2 relay outputs (SPDT) |
| Communication | RS485 (Modbus RTU) |
| Power Supply | 85-265V AC/DC |
| Protection | IP65 (front panel) |
| Dimensions | 96x96x55 mm |
| Mounting | Panel mount |
Product Data Sheet
