Product Description – A9N2P16C

Miniature Circuit Breaker – xC60 – 2 Poles – 16 A – C Curve – Schneider Electric

Product Code: A9N2P16C

Brand: Schneider Electric

Series: xC60

Type: Miniature Circuit Breaker (MCB)

Number of Poles: 2 Poles

Rated Current: 16 A

Tripping Curve: C Curve

Breaking Capacity: 6 kA at 230/400V AC

Voltage Rating: 230/400V AC

Frequency: 50/60 Hz

Mounting Type: DIN Rail Mounting

Terminal Type: Screw Clamp

Operating Temperature: -25°C to +60°C

Storage Temperature: -40°C to +70°C

Standards: IEC/EN 60898-1, IEC/EN 60947-2

Mechanical Life: 20,000 cycles

Electrical Life: 10,000 cycles

Protection Degree: IP20 (when installed in a suitable enclosure)

Dimensions: 36 mm (width) x 78 mm (height) x 68 mm (depth)

Weight: Approx. 0.2 kg

Color: White

Application: Suitable for residential, commercial, and industrial applications. Provides protection against overloads and short circuits.

Features:

• Compact design for space-saving installation
• High breaking capacity for reliable protection
• Easy to install and operate
• Complies with international standards for safety and performance
• Durable construction for long service life

Warranty: Standard manufacturer warranty applies.
