LC1D09B7 | TeSys D Contactor – 3P(3 NO) – AC-3 – <= 440 V 9 A – 24 V AC Coil

Product Description

The LC1D09B7 is a TeSys D contactor manufactured by Schneider Electric. It is designed for controlling three-phase motors and other electrical loads. This contactor is part of the TeSys D range, known for its reliability and durability in industrial applications.

Key Features

• Type: Contactor
• Number of Poles: 3P (3 Normally Open Contacts)
• Rated Operational Voltage (Ue): Up to 440 V AC
• Rated Operational Current (Ie): 9 A (AC-3)
• Coil Voltage: 24 V AC
• Utilization Category: AC-3 (Squirrel cage motors: starting, switching off)
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Mounting: Screw mounting or snap-on mounting on 35 mm DIN rail
• Terminal Type: Screw terminals
• Dimensions: Compact design for space-saving installation
• Standards: Complies with IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No. 14
• Environmental Compliance: RoHS compliant

Applications

The LC1D09B7 contactor is suitable for a wide range of applications, including:

• Motor control in industrial machinery
• HVAC systems
• Pump control
• Conveyor systems
• Lighting control

Additional Information

This contactor is designed for easy installation and maintenance. It features a robust construction that ensures reliable performance even in harsh environments. The 24 V AC coil makes it suitable for low-voltage control circuits, providing safety and flexibility in various applications.

Warranty

Schneider Electric offers a standard warranty on this product, subject to terms and conditions. Please refer to the official documentation or contact Schneider Electric for detailed warranty information.
