The Schneider Electric SXWSBTHCXSXX is a humidity & temperature controller from the SpaceLogic range, engineered for industrial, commercial, and infrastructure applications in demanding Indian and international installations. Key ratings include IP20. Buy the SXWSBTHCXSXX | Sensor Base,Temp,Humidity,Co2 online at myelectric.in with GST invoice, genuine-product assurance, and fast delivery across India — bulk and worldwide export enquiries welcome.

📋 Technical Specifications

Product
Brand	Schneider Electric
Part Number / SKU	SXWSBTHCXSXX
Category	Humidity & Temperature Controller
Main
Product or component type	Sensor
Type of measurement	Carbon dioxide (CO2) Humidity Temperature
location	Living space
Sensor type	Transmitter
CO2 measurement range	0…50 °C temperature 0…2000 ppm 0…100 % RH
Colour	White
Communication port protocol	RJ45
Depth	20.7 mm
Height	111.6 mm
Width	81.2 mm
Display type	Without display
IP degree of protection	IP20
Local signalling	1 LED calibration (CAL)
Relative humidity	0…95 %
Ambient air temperature for operation	0…50 °C
Output type	Sensor bus
Flame retardance	UL94-V0
Power consumption in W	2 W
Product certifications	CE EAC RCM ICES-003
Standards	UL 916 FCC part 15 class B
[Us] rated supply voltage	24 V DC
Product name	SmartX Living Space Sensor
Range	SpaceLogic
Complementary
Device presentation	Without cover
Function available	With temperature sensor With CO2 sensor With humidity sensor
Hysteresis	1.5 %
Supply	Via bus connector
Material	ABS (acrylonitrile butadiene-styrene) GF10 FR
Range compatibility	EcoStruxure Building Operation SmartX Room Purpose Controller programmable controllers EcoStruxure Building Operation SmartX Living Space Sensor sensor coverplate
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	4.826 cm
Package 1 Width	9.652 cm
Package 1 Length	14.224 cm
Package 1 Weight	128.049 g
Unit Type of Package 2	CAR
Number of Units in Package 2	40
Package 2 Height	29.464 cm
Package 2 Width	29.464 cm
Package 2 Length	39.624 cm
Package 2 Weight	6.164 kg
Unit Type of Package 3	PAL
Number of Units in Package 3	1200
Package 3 Height	111.760 cm
Package 3 Width	101.600 cm
Package 3 Length	121.920 cm
Package 3 Weight	204.116 kg
Contractual warranty
Warranty (in months)	18

⚡ Key Features

Manufactured to IS/IEC 60947, IS 8828 (MCBs), IS 13947, IEC 61439 (DBs) — complies with Indian BIS and IEC international safety standards.
BIS certified, CE marked, RoHS compliant — meets Indian regulatory requirements for use in government, commercial, and industrial electrical installations.
Genuine authorised Schneider Electric product — sourced directly from the official distribution network with full manufacturer traceability and warranty.
GST invoice provided for India orders — valid for corporate procurement, government project orders, and public tender supply via myelectric.in.
Worldwide export available — UAE, Singapore, UK, USA, Sri Lanka & more. Contact +91 94814 00316 for bulk pricing and international shipping.
