LC1E18008M5WBIN – Easy TeSys Contactor

Product Description

The LC1E18008M5WBIN is a 4-pole contactor from Schneider Electric’s Easy TeSys series, designed for reliable switching of electrical circuits. It is suitable for a wide range of industrial and commercial applications, offering high performance and durability.

Key Features

• Type: Contactor
• Poles: 4P (4 Poles)
• Rated Current: 40A (AC1)
• Contact Configuration: 2NO (Normally Open) + 2NC (Normally Closed)
• Rated Voltage: 220V AC
• Frequency: 50Hz
• Mounting: Screw Mounting
• Terminal Type: Screw Clamp
• Coil Voltage: 220V AC
• Enclosure Material: Thermoplastic
• IP Rating: IP20 (Protection against touch by fingers and objects greater than 12.5mm)
• Operating Temperature: -25°C to +60°C
• Mechanical Life: 10 million operations
• Electrical Life: 1 million operations
• Weight: Approximately 0.5 kg
• Compliance: IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14

Applications

The LC1E18008M5WBIN is ideal for use in motor control, lighting control, and other general-purpose switching applications. It is commonly used in HVAC systems, pumps, compressors, and other industrial machinery.

Benefits

• High reliability and long service life
• Compact design for space-saving installation
• Easy to install and maintain
• Compatible with a wide range of accessories
• Complies with international standards for safety and performance

Dimensions

Dimensions: 90mm (H) x 45mm (W) x 80mm (D)

Warranty

Schneider Electric offers a standard warranty of 2 years from the date of purchase, subject to terms and conditions.
