LC1D09M7 | TeSys D Contactor – Schneider Electric

Product Overview

The LC1D09M7 is a TeSys D contactor from Schneider Electric, designed for reliable switching of electrical loads. It is suitable for a wide range of industrial and commercial applications, offering high performance and durability.

Key Features

• Type: Contactor
• Poles: 3P (3 Normally Open Contacts)
• Rated Operational Voltage (Ue): ≤ 440 V AC
• Rated Operational Current (Ie): 9 A (AC-3)
• Coil Voltage: 220 V AC
• Utilization Category: AC-3 (Squirrel cage motors: starting, switching off)
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Mounting: Screw mounting or snap-on mounting on 35 mm DIN rail
• Terminal Type: Screw terminals
• Dimensions: Compact design for space-saving installation
• Standards Compliance: IEC/EN 60947-4-1, UL 60947-4-1, CSA C22.2 No. 14
• Environmental Protection: IP20 (finger-safe protection)
• Ambient Temperature: -25°C to +60°C
• Storage Temperature: -55°C to +85°C

Applications

The LC1D09M7 contactor is ideal for controlling three-phase motors, heating systems, and other electrical loads in various industries, including manufacturing, HVAC, and automation.

Benefits

• High reliability and long service life
• Compact and modular design for easy installation
• Compatible with a wide range of accessories (e.g., auxiliary contacts, timers)
• Energy-efficient coil design
• Global certifications for use in multiple regions

Additional Information

For more details, refer to the official Schneider Electric product documentation or contact their technical support team.
